WIN Windspeed & Direction Sensor

WIN Windspeed and Direction Sensor

  • Wind Speed Measuring Range 0.7 - 55.6m/s (2.2 - 200km/h)
  • Wind Direction Measuring Range 0 to 360 degrees
  • Maintenance Free Both sensors are maintenance free apart from a periodical cleaning of moving parts
  • Telemetry Ready Connects to A753, A755, A723 Adcon Telemetry Units
Product Options

Case Studies

Overview

The WIN Wind Speed and Direction sensor is constructed around an AC generator (without brushes) and a rectifier, and all external sensor parts are made of highly resistive plastics. No maintenance is required for either sensor (except for periodical cleaning to free moving parts from e.g. cob webs) and the sensors maintain their original accuracy for many years. The statistical drop out rate of the sensor is less than 3 % within the first 8 years of operation.

The Wind Direction sensor is based on a precision potentiometer, and with a very low starting speed it can measure up to 200 km/h.

Made in Switzerland to the highest specifications, with permanent quality control based on an ISO-9000 equivalent Norm, executed by SCS, provides the product with the "Swiss-Calibration" quality mark. According to multilateral agreements this quality mark is approved and accepted in the following countries: A, CH, D, DK, F, GB, IE, I, N, NL, S, SF, RSA

The windspeed and direction sensor is supplied with a mast mounting arm, 2 pipe clamps, 2m of cable and some cable ties.

Manufactured by: Adcon Telemetry
Model: WIN Windspeed and Direction Sensor

Services offered for this product

  • Sales
  • Rental
  • Installation
  • Calibration
  • Maintenance

Applications

Economy wind speed and direction monitoring

Specification

Wind Speed
Measuring Range 0.7 - 55.6m/s (2.2 - 200km/h)
Linearity ±0.3m/s & ± 2% rdg @ 20°C
Onset Speed 0.6m/s (2.2 km/h)
Operating Temperature -30°C to +65°C
Wind Direction
Measuring Range 0° - 36°
Measuring Device Potentiometer
Linearity ± 1%
Dead Angle 3° ± 1°
Switching Point North
Onset Speed 0.6m/s (2.2 km/h)
Connectior 7 pin Binder jack (male)
Cable 2m
