Portable pH meter - CyberScan pH 610

CyberScan pH 610

  • Warranty Covered by 3 year meter warranty
  • Comprehensive Screen Large one-glance-tells-all-screen display with backlight
  • Complimentary Software Complete with Eutech CyberComm 600 DAS software
Product Options
ECPHWP61042K

Overview

The CyberScan pH 610 features 6 calibration points and 20 auto/manual buffer options sets for quick, convenient calibration, high accuracy results under varying temperatures with a choice of automatic or manual temperature compensation. The unit features a large screen which displays electrode status, calibration information along with temperature and pH or Ion measurements. This comes cased in a rugged and waterproof housing to meet IP67 standard with protective rubber boot and handy Velcro strap means the device can be used safely in the field or at the bench-top.

The CyberScan pH 610 has space to store/recall up to 500 data sets with temperature readings time and date stamped formatted to meet GLP standards. Volatile memory holds settings and stored data which can be powered either by batteries or AC adapter and delivers high accuracy results of up to ±0.002 at resolution expendable to 3 decimal points. A hold function enables results to be momentarily frozen on screen for easy viewing and recording

Other features which make the CyberScan pH 610 the ideal choice are cal-due alarm which prevents out dated calibrations whilst the set-point alarm feature warns when readings are outside set point limits. Recall electrode slope, electrode offset value and previous calibration values are provided for easy reference. This device also features self diagnostics with message codes for easy troubleshooting.

Data can be transferred using wireless and cable free infrared IrDA technology or can be downloaded using the PC based complimentary Data Acquisition Software which imports data and generates reports into any popular software program of your choice.

This product is covered by a 3 year meter warranty.

Manufactured by: Eutech Instruments
Model: CyberScan pH 610

Services offered for this product

  • Sales
  • Rental
  • Installation
  • Calibration
  • Maintenance

Applications

Water conditioning plants
Conditioning plants
Cooling Towers
Food processing water testing
Printing and chemical testing
Water/wastewater treatment
Ecology Studies
Aquariums
Hydroponics
pH checks in laboratories and schools

Specification

pH Range -2.000 to 19.999 pH
Resolution & Accuracy (±1 LSD) 0.1 0.01/ 0.001±0.002 pH
mV Range ±2000 mV
Resolution & Accuracy (±1 LSD) 0.1 mV &±0.2 mV
Temperature Range -10.0 to 110.0 °C (14.0 to 230 °F)
Resolution & Accuracy 0.1 °C/ 1.0°F
Temperature Compensation Automatic / Manual (0 to 100 °C)
No. of Calibration Points Up to 6 points
Cal Due Alarm Yes (Days - Max 30)
pH Buffer Options USA, NIST, DIN, PWB
Custom Buffer Calibration Yes (2 to 5)
Slope/ Offset Display Yes (Display + Icon)
Inputs DC phono sockets, 8 pin connector, BNC
LCD Display Back-lit Dot Matrix
Memory 500 data sets
Output Yes (IrDA/ RS232C)
Special Functions Stability Indicator; Self-diagnostic; Non-Volatile Memory; Hold & Auto-Power Off after 20 minutes
GLP Yes
Ingress Protection IP67
Power 4 ‘'AAA’' x 1.4V batteries or 9VDC power adapter
