3001 BioFoul Screen

  • Long Term Performance Ensures reliable conductivity and pressure measurements
  • Extended Deployment Periods Uses natural anti-fouling characteristics of copper
  • An Affordable Option Reduces the need for maintenance
Product Options
110659

Overview

Solinst have produced the Model 3001 BioFoul Screen purposefully for use with the levelogger Edge, Levelogger Junior Edge or the LTC Levelogger Junior to extend the time a Levelogger is deployed for before maintenance is required. When a Levelogger is deployed for extended periods in costal and saltwater environments there is and increased risk of biofouling, consequently the build up of biofoul on the pressure sensor or the conductivity cell can compromise reliability of readings. The Model 3001 BioFoul Screen is now the perfect user friendly option, consisting of a Delrin sleeve wrapped in copper wire that simply slips onto the sensor end of the Levelogger where it is held in place by friction fit. Water can still freely enter the pressure sensor of any levelogger and conductivity cell of an LTC without compromising the results.

Historically Leveloggers have and can still be cleaned by soaking them for a short amount of time in a very weak acid solution, although this is perfectly suitable for cleaning loggers it can also be time consuming, increase maintenance costs and trips to the field.

The BioFoul Screen uses natural anti-fouling characteristics of copper which reduce the unwanted buildup of microorganisms, plants, algae or organisms such as barnacles and mussels.



Manufactured by: Solinst
Model: 3001 BioFoul Screen

Services offered for this product

  • Sales
  • Rental
  • Installation
  • Calibration
  • Maintenance

Applications

Surface water monitoring in freshwater or saltwater
Harbour and tidal fluctuation monitoring
Monitoring at aquariums and aquaculture operations
Mine water, wastewater and landfill leachate monitoring
Monitoring in oceans, lakes, wetlands or estuaries

Downloads

FAQ's

Water level data from remote Leveloggers can be sent using the model 9500 LevelSender, which uses a GSM cellular modem to send the data to a home computer station or mobile device via email/SMS.
Leveloggers are connected to LevelSenders using a Reader cable which connects to the Levelogger’s Direct Read Cable. This can be done by removing the black dust cap from the LevelSender, lining up the holes and pushing the Reader Cable connector into the LevelSender connection and screwing the Reader Cable into the connection on the LevelSender until tight. Then connect the other end of the reader cable to the top end of the Levelogger’s direct read cable.
Within the diagnostic utility there is an option called ‘read memory dump’ this will access previous logs from a backup location. This dumps all of the Leveloggers memory into a .xle file.

The free app is available on both Apple® and Android™ smart devices.
Apple devices must be running iOS 11 or later on the following compatible devices:

  • iPhone
  • iPad
  • iPad mini
  • iPod touch.

Android devices must be running version 5.0 or higher. Solinst does not guarantee compatibility on all devices running 5.0, but testing confirms the following can be used:

  • Phone: Samsung Galaxy S4 - Model SGH-1337M
  • Phone: Samsung Galaxy S5 - Model SM-G900W8
  • Tablet: Samsung Tab 4 (10.1”) - Model SM-T530NU

As the Levelogger App Interface will not connect directly to the top of a Solinst datalogger, it is necessary to have connection accessories. With the Levelogger or Rainlogger, one of the following accessories is required:

  • Direct Read Cable, clients use this option to suspend dataloggers in the field when they wish to communicate downhole.
  • When working with Leveloggers that are suspended from wireline, or cord, the units must be removed from the well and connected to either a Direct Read Cable (as above) or an Optical Adaptor.
  • For the LevelVent, just connect to the unit via the Vented Cable and LevelVent Wellhead that all units are suspended from in the field – no other connection accessories are required.
  • The AquaVent communication connection is made from the App Interface to the AquaVent Wellhead using an App Connector Cable that is ordered separately.
The Levelogger App Interface is portable hardware that connects to the top of your Levelogger via a Direct Read Cable/Adaptor, to a LevelVent Wellhead, or to an AquaVent Wellhead cable. Bluetooth wireless technology allows communication between the Levelogger App Interface and the smart device with the app installed. It allows viewing/downloading of data, and programming of Solinst dataloggers, as well as many other features.
Solinst offers a wide range of dataloggers that can be used with the Leveloggger App Interface. They include the complete, current Levelogger Edge range of units (Edge, Junior Edge, LTC Edge, Rainlogger Edge), previous Gold Leveloggers/Barologgers, and the latest vented datalogger editions, the AquaVent and LevelVent.
  • Program and start dataloggers in the field.
  • Simplify data management in the field by transporting and using less equipment.
  • View real-time readings.
  • Download and e-mail logged data files.
  • Calibrate LTC Leveloggers (NEW).
  • Run the diagnostic utility (NEW) – used for troubleshooting

Leveloggers. Provides detailed information on the datalogger,
and includes options for running a self-test, doing a memory
dump and creating/emailing reports.

Follow these links to some step by step tutorials from Solinst to ensure your USB driver is installed correctly: Windows 7, Windows 8, Windows 10
